CHEMI-CON 1mF Through Hole Polymer Capacitor, 16V dc
- RS Stock No.:
- 174-9927
- Mfr. Part No.:
- APSG160ELL102MH20S
- Manufacturer:
- CHEMI-CON
Bulk discount available
Subtotal (1 pack of 25 units)**
MYR59.15
775 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Real time qty checker
Units | Per Unit | Per Pack** |
|---|---|---|
| 25 - 25 | MYR2.366 | MYR59.15 |
| 50 - 75 | MYR2.283 | MYR57.075 |
| 100 + | MYR2.169 | MYR54.225 |
**price indicative
- RS Stock No.:
- 174-9927
- Mfr. Part No.:
- APSG160ELL102MH20S
- Manufacturer:
- CHEMI-CON
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Technology | Polymer | |
| Capacitance | 1mF | |
| Voltage | 16V dc | |
| Dielectric Material Family | Aluminium | |
| Mounting Type | Through Hole | |
| Equivalent Series Resistance | 8mΩ | |
| Lead Pitch | 3.5mm | |
| Tolerance | ±20% | |
| Maximum Operating Temperature | +105°C | |
| Height | 20mm | |
| Dimensions | 8 (Dia) x 20mm | |
| Series | PSG | |
| Electrolyte Type | Solid | |
| Diameter | 8mm | |
| Leakage Current | 500 μA | |
| Polarised | Polar | |
| Ripple Current | 7500mArms | |
| Dissipation Factor | 12% | |
| Minimum Operating Temperature | -55°C | |
| Lifetime | 1000h | |
