Units	Per Unit	Per Pack**
25 - 25	MYR4.038	MYR100.95
50 - 75	MYR3.953	MYR98.825
100 +	MYR3.834	MYR95.85

Select all	Attribute	Value
	Brand	CHEMI-CON
	Technology	Polymer
	Capacitance	1.5mF
	Voltage	16V dc
	Dielectric Material Family	Aluminium
	Mounting Type	Through Hole
	Equivalent Series Resistance	8mΩ
	Lead Pitch	5mm
	Tolerance	±20%
	Length	16mm
	Height	16mm
	Maximum Operating Temperature	+105°C
	Dimensions	10 (Dia) x 16mm
	Series	PSG
	Electrolyte Type	Solid
	Lifetime	1000h
	Leakage Current	500 μA
	Polarised	Polar
	Diameter	10mm
	Dissipation Factor	0.12%
	Minimum Operating Temperature	-55°C
	Ripple Current	7700mArms

	Select all
	Brand CHEMI-CON
	Technology Polymer
	Capacitance 1.5mF
	Voltage 16V dc
	Dielectric Material Family Aluminium
	Mounting Type Through Hole
	Equivalent Series Resistance 8mΩ
	Lead Pitch 5mm
	Tolerance ±20%
	Length 16mm
	Height 16mm
	Maximum Operating Temperature +105°C
	Dimensions 10 (Dia) x 16mm
	Series PSG
	Electrolyte Type Solid
	Lifetime 1000h
	Leakage Current 500 μA
	Polarised Polar
	Diameter 10mm
	Dissipation Factor 0.12%
	Minimum Operating Temperature -55°C
	Ripple Current 7700mArms

CHEMI-CON 1.5mF Through Hole Polymer Capacitor, 16V dc

FREE delivery for orders over MYR500.00
