Molex KK 254 Series Straight Through Hole Pin Header, 7 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 479-197
- Mfr. Part No.:
- 22-03-2071
- Manufacturer:
- Molex
Temporarily out of stock - back order for despatch 03/12/2024, delivery within 4 working days from despatch date
Added
Price Each (In a Pack of 10)
MYR3.489
| Units | Per Unit | Per Pack* |
| 10 - 240 | MYR3.489 | MYR34.89 |
| 250 - 990 | MYR3.349 | MYR33.49 |
| 1000 + | MYR3.208 | MYR32.08 |
| *price indicative | ||
- RS Stock No.:
- 479-197
- Mfr. Part No.:
- 22-03-2071
- Manufacturer:
- Molex
Legislation and Compliance
Product Details
Straight PCB Headers
Headers are available in single-row, unshrouded, through-hole PCB termination styles in solid and breakaway varieties. A friction lock is available for a more secure mating interface. KK 254 PCB receptacles are available in right-angle, top-entry and board-through configurations. Housings have built-in polarization features and are available in UL 94V-2 and UL 94V-0 nylons.
Approvals
UL (E29179) and CSA (LR 19980)
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Series | KK 254 |
| Pitch | 2.54mm |
| Number of Contacts | 7 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board to Board, Wire to Board |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Contact Plating | Tin |
| Contact Material | Brass |
| Series Number | 4030 |
| Current Rating | 4.0A |
| Voltage Rating | 250 V |
