Wurth Elektronik WCAP-FTXX Polypropylene Capacitor PP, 310V ac, ±10%, 820nF, Through Hole
- RS Stock No.:
- 871-2619
- Mfr. Part No.:
- 890334026024CS
- Manufacturer:
- Wurth Elektronik
Temporarily out of stock - back order for despatch 14/11/2024, delivery within 4 working days from despatch date
Added
Price Each (In a Bag of 5)
MYR5.91
| Units | Per Unit | Per Bag* |
| 5 - 45 | MYR5.91 | MYR29.55 |
| 50 - 95 | MYR5.786 | MYR28.93 |
| 100 + | MYR5.612 | MYR28.06 |
| *price indicative | ||
- RS Stock No.:
- 871-2619
- Mfr. Part No.:
- 890334026024CS
- Manufacturer:
- Wurth Elektronik
Technical data sheets
Legislation and Compliance
Product Details
Wurth Elektronik Polypropylene Film Capacitors, WCAP-FTXX Series
WCAP-FTXX Series are MKP Metallized Polypropylene Film
Self-healing properties
Operating temperature: -40 °C to +105°C
Wave soldering recommended
Applications include: Safety applications, Filter and Power Supplies
Operating temperature: -40 °C to +105°C
Wave soldering recommended
Applications include: Safety applications, Filter and Power Supplies
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Radial 105°C
Encapsulated in self-extinguishing material meeting the requirements of UL94V-0
Specifications
Attribute | Value |
|---|---|
| Capacitance | 820nF |
| Voltage | 310V ac |
| Mounting Type | Through Hole |
| Tolerance | ±10% |
| Series | WCAP-FTXX |
| Lead Pitch | 22.5mm |
| Suppression Class | X2 |
| Length | 26mm |
| Depth | 9mm |
| Lead Length | 4mm |
| Height | 18mm |
| Dimensions | 26 x 9 x 18mm |
| Terminal Type | Through Hole |
| Minimum Operating Temperature | -40°C |
| Lead Diameter | 0.8mm |
| Maximum Operating Temperature | +105°C |
| Dissipation Factor | <0.70 % @ 100 kHz |
