ZF Door Micro Switch, Plunger, SPDT 100 mA Thermoplastic Polyester, -40 → +85°C
- RS Stock No.:
- 868-1711
- Mfr. Part No.:
- 0E68-00A0
- Manufacturer:
- ZF
Subtotal (1 unit)*
MYR43.10
FREE delivery for orders over RM 500.00
In Stock
- Plus 884 unit(s) shipping from 22 September 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per Unit |
|---|---|
| 1 + | MYR43.10 |
*price indicative
- RS Stock No.:
- 868-1711
- Mfr. Part No.:
- 0E68-00A0
- Manufacturer:
- ZF
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ZF | |
| Actuator Type | Plunger | |
| Contact Configuration | SPDT | |
| Contact Current Rating | 100 mA | |
| Terminal Type | Quick Connect | |
| Contact Material | Gold Plated | |
| Operating Force | 4.25 N | |
| Case Material | Thermoplastic Polyester | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Width | 39.88mm | |
| Operating Temperature Range | -40 → +85°C | |
| Depth | 46.87mm | |
| Length | 17.27mm | |
| Standards Met | UL Listed | |
| Dimensions | 17.27 x 39.88 x 46.87mm | |
Select all | ||
|---|---|---|
Brand ZF | ||
Actuator Type Plunger | ||
Contact Configuration SPDT | ||
Contact Current Rating 100 mA | ||
Terminal Type Quick Connect | ||
Contact Material Gold Plated | ||
Operating Force 4.25 N | ||
Case Material Thermoplastic Polyester | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Width 39.88mm | ||
Operating Temperature Range -40 → +85°C | ||
Depth 46.87mm | ||
Length 17.27mm | ||
Standards Met UL Listed | ||
Dimensions 17.27 x 39.88 x 46.87mm | ||
