Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	onsemi
	Package Type	SOIC
	Display Type	LED
	Number of Pins	10
	Supply Voltage	4.5 → 40 V
	Number of Segments	1
	Maximum Supply Current	1.2mA
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	+125°C
	Mounting Type	Surface Mount
	Width	3.9mm
	Height	1.25mm
	Length	4.9mm

	Select all
	Brand onsemi
	Package Type SOIC
	Display Type LED
	Number of Pins 10
	Supply Voltage 4.5 → 40 V
	Number of Segments 1
	Maximum Supply Current 1.2mA
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature +125°C
	Mounting Type Surface Mount
	Width 3.9mm
	Height 1.25mm
	Length 4.9mm

Datasheet NCL30170ADR2G

COO (Country of Origin):: TW

Accurate LED CC regulation: <±1%
Workable for Constant Power regulation
Selectable LED Channel counts
High PF & Low THD : >0.99 / <10%
Proprietary Active Phase-Cut Dimmer Control Technique
Wide Analog Dimming range: 5∼100%
HV Startup Current Source
Protections - Input Over Voltage Protection - RCS Short Protection - Thermal Shutdown
Excellent Light Uniformity
Flexible Design
Easy Power Scalability 5∼300 W
Overpass global standard
Excellent Phase-cut dimmer Compatibility
Flexible Smart Lighting Design
Fast start up & Low eBOM
High System Reliability
Applications
LED Light - Non-Dimming, Phase-Cut Dimming, Analog Dimming (0-10)
End Products
LED Light - PAR, Down, Tube, Flat, Ceiling, Flood, High Bay, Street Light

Units	Per Unit	Per Pack*
7 - 623	MYR6.599	MYR46.19
630 - 1246	MYR6.27	MYR43.89
1253 +	MYR5.956	MYR41.69

onsemi NCL30170ADR2G SOIC Display Driver, 1 Segment, 10 Pin, 4.5 → 40 V

FREE delivery for orders over RM 500.00

For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.
