C & K 10 Way Through Hole DIP Switch SPST, Side Actuator
- RS Stock No.:
- 793-1563
- Mfr. Part No.:
- BPA10B
- Manufacturer:
- C & K
41 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each
MYR12.53
| Units | Per Unit |
| 1 - 14 | MYR12.53 |
| 15 - 59 | MYR12.15 |
| 60 - 149 | MYR11.78 |
| 150 - 599 | MYR11.52 |
| 600 + | MYR11.27 |
- RS Stock No.:
- 793-1563
- Mfr. Part No.:
- BPA10B
- Manufacturer:
- C & K
Technical data sheets
Legislation and Compliance
Product Details
C & K BPA Series Through Hole Mount
Side actuated full profile DIP switches from C & K that feature a high pressure contact system that does not require a tape seal for washing
Switch contact rating: 100 mA @ 5 V dc / 25 mA @ 24 V dc
Electrical Life: 1000 cycles minimum
Electrical Life: 1000 cycles minimum
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 10 |
| Mounting Type | Through Hole |
| Contact Material | Gold over Nickel Plated Copper Beryllium |
| Contact Configuration | SPST |
| Package Style | DIP |
| Actuator Type | Side |
| Contact Current Rating | 25 mA@ 24 V dc |
| Mechanical Life | 1000Cycles |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -20°C |
| Operating Temperature Range | -20 → +85°C |
