Switchcraft DC Power Plug Rated At 5A, 30 V dc, Cable Mount, length 57.1mm, Nickel, IP68

  • RS Stock No. 705-1513
  • Mfr. Part No. S761ks15
  • Manufacturer Switchcraft
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): US
Product Details

IP68 DC Power Plugs

2-conductor power jacks
Hollow centre pin
Locking option for added security in critical applications
Black molded plastic handles
Sleeve terminal serves as cord clamp

Plugs & Sockets

Miniature plugs suitable for powering portable radios, calculators plus test and measurement instruments from a fixed, low-voltage d.c. source. Chassis mounting sockets for the 2.1mm plugs and adaptor leads terminated with 2.1mm and 2.5mm plugs and sockets are also available. Contacts are nickel/silver plated brass.Connector bodies are moulded in ABS plastic

Attribute Value
Current Rating 5.0A
Inner Diameter 2.1mm
Outer Diameter 5.5mm
Body Orientation Straight
Voltage Rating 30 V dc
Length 57.1mm
Mounting Type Cable Mount
IP Rating IP68
Minimum Cable Diameter 3.8mm
Maximum Cable Diameter 4.4mm
Contact Plating Nickel
Contact Material Copper Alloy
1 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 25.61
Per unit
1 - 14
15 - 49
50 +
