Cosel MGW DC-DC Converter, ±12V dc/ 250mA Output, 4.5 → 9 V dc Input, 6W, PCB Mount, +85°C Max Temp -40°C Min
- RS Stock No.:
- 171-5209
- Mfr. Part No.:
- MGW60512
- Manufacturer:
- Cosel
Bulk discount available
Subtotal (1 unit)**
MYR99.80
29 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ*
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over MYR500.00
Real time qty checker
Units | Per Unit |
|---|---|
| 1 - 2 | MYR99.80 |
| 3 - 4 | MYR96.80 |
| 5 + | MYR93.80 |
**price indicative
- RS Stock No.:
- 171-5209
- Mfr. Part No.:
- MGW60512
- Manufacturer:
- Cosel
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage | ±12V dc | |
| Input Voltage Range | 4.5 → 9 V dc | |
| Power Rating | 6W | |
| Input Voltage Nominal | 5 V dc | |
| Output Current | 250mA | |
| Mounting Type | PCB Mount | |
| Isolated | Yes | |
| Number of Outputs | 2 | |
| Package | SIP 8 | |
| Isolation Voltage | 1kV dc | |
| Length | 22mm | |
| Depth | 12mm | |
| Width | 9.5mm | |
| Series | MGW | |
| Load Regulation | 600mV | |
| Minimum Temperature | -40°C | |
| Maximum Temperature | +85°C | |
| Efficiency | 87% | |
Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage ±12V dc | ||
Input Voltage Range 4.5 → 9 V dc | ||
Power Rating 6W | ||
Input Voltage Nominal 5 V dc | ||
Output Current 250mA | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 2 | ||
Package SIP 8 | ||
Isolation Voltage 1kV dc | ||
Length 22mm | ||
Depth 12mm | ||
Width 9.5mm | ||
Series MGW | ||
Load Regulation 600mV | ||
Minimum Temperature -40°C | ||
Maximum Temperature +85°C | ||
Efficiency 87% | ||
