Cosel MGS DC-DC Converter, 5V dc/ 1.2A Output, 4.5 → 9 V dc Input, 6W, PCB Mount, +85°C Max Temp -40°C Min Temp

RS Stock No.:: 171-5034
Mfr. Part No.:: MGS60505
Manufacturer:: Cosel

Cosel MGS DC-DC Converter, 5V dc/ 1.2A Output, 4.5 → 9 V dc Input, 6W, PCB Mount, +85°C Max Temp -40°C Min Temp

19 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ

Added

Price Each

MYR98.81

Units	Per Unit
1 - 2	MYR98.81
3 - 4	MYR95.84
5 +	MYR92.87

RS Stock No.:: 171-5034
Mfr. Part No.:: MGS60505
Manufacturer:: Cosel

Technical data sheets

Datasheet

Legislation and Compliance

COO (Country of Origin):: JP

Product Details

Industry Standard
1"X1" (MGS15) , 1"X2" (MGS30)
High efficiency by synchronized rectification circuit (MGS10/MGS15/MGS30)
6 sided shield (MGS15/MGS30)
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in overvoltage protection circuits (MGS30)
Built-in remote ON/OFF (MGS6/MGS10/MGS15/MGS30)
Output voltage adjustability by external variable resistor (MGS15/MGS30)
High reliability : not built-in aluminium and tantalum electrolytic capacitor

Industry Standard
I/O isolation voltage DC1,500V (1 minute)
Built-in overcurrent protection circuits (recovers automatically)
Built-in remote ON/OFF
High reliability : not built-in aluminium and tantalum electrolytic capacitor

For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.

Specifications

Attribute	Value
Output Voltage	5V dc
Input Voltage Range	4.5 → 9 V dc
Power Rating	6W
Input Voltage Nominal	5 V dc
Output Current	1.2A
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	1
Package	SIP 8
Isolation Voltage	1kV dc
Length	22mm
Depth	12mm
Width	9.5mm
Series	MGS
Load Regulation	20mV
Maximum Temperature	+85°C
Minimum Temperature	-40°C
Efficiency	85%
