Units	Per Unit
1 - 4	MYR240.87
5 - 9	MYR233.64
10 - 24	MYR226.41
25 - 49	MYR221.60
50 +	MYR216.78

Select all	Attribute	Value
	Brand	Cosel
	Output Voltage	3.3V dc
	Input Voltage Range	36 → 76 V dc
	Power Rating	26.4W
	Input Voltage Nominal	48 V dc
	Output Current	8A
	Mounting Type	PCB Mount
	Isolated	Yes
	Number of Outputs	1
	Output Voltage Adjustment Range	±10%
	Isolation Voltage	1.5 kV ac, 500V dc
	Length	25.4mm
	Depth	9.9mm
	Width	50.8mm
	Series	MGS
	Load Regulation	13.2mV
	Maximum Temperature	+85°C
	Efficiency	91%
	Standards Met	CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1
	Minimum Temperature	-40°C

	Select all
	Brand Cosel
	Output Voltage 3.3V dc
	Input Voltage Range 36 → 76 V dc
	Power Rating 26.4W
	Input Voltage Nominal 48 V dc
	Output Current 8A
	Mounting Type PCB Mount
	Isolated Yes
	Number of Outputs 1
	Output Voltage Adjustment Range ±10%
	Isolation Voltage 1.5 kV ac, 500V dc
	Length 25.4mm
	Depth 9.9mm
	Width 50.8mm
	Series MGS
	Load Regulation 13.2mV
	Maximum Temperature +85°C
	Efficiency 91%
	Standards Met CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1
	Minimum Temperature -40°C

Cosel MGS DC-DC Converter, 3.3V dc/ 8A Output, 36 → 76 V dc Input, 26.4W, PCB Mount, +85°C Max Temp -40°C Min

FREE delivery for orders over MYR500.00

MGS Series, On/Off Remote Function

Features and Benefits
