Units	Per Unit
1 - 4	MYR202.87
5 - 9	MYR196.78
10 - 24	MYR190.71
25 - 49	MYR186.65
50 +	MYR182.58

Select all	Attribute	Value
	Brand	Cosel
	Output Voltage	±12V dc
	Input Voltage Range	18 → 76 V dc
	Power Rating	15.6W
	Input Voltage Nominal	48 V dc
	Output Current	650mA
	Mounting Type	PCB Mount
	Isolated	Yes
	Number of Outputs	2
	Output Voltage Adjustment Range	11.765 → 12.492V
	Isolation Voltage	500V dc
	Width	25.4mm
	Length	25.4mm
	Depth	9.9mm
	Series	MGFW
	Load Regulation	480mV
	Efficiency	87%
	Standards Met	CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1
	Maximum Temperature	+85°C
	Minimum Temperature	-40°C

	Select all
	Brand Cosel
	Output Voltage ±12V dc
	Input Voltage Range 18 → 76 V dc
	Power Rating 15.6W
	Input Voltage Nominal 48 V dc
	Output Current 650mA
	Mounting Type PCB Mount
	Isolated Yes
	Number of Outputs 2
	Output Voltage Adjustment Range 11.765 → 12.492V
	Isolation Voltage 500V dc
	Width 25.4mm
	Length 25.4mm
	Depth 9.9mm
	Series MGFW
	Load Regulation 480mV
	Efficiency 87%
	Standards Met CE, cUL, cULus Recognised, EN 60950-1, TUV, UL 60950-1
	Maximum Temperature +85°C
	Minimum Temperature -40°C

Cosel MGFW DC-DC Converter, ±12V dc/ 650mA Output, 18 → 76 V dc Input, 15.6W, PCB Mount, +85°C Max Temp -40°C

FREE delivery for orders over MYR500.00

MGFW Series, On/Off Remote Function

Features and Benefits
