    TDK-Lambda CC-E DC-DC Converter, 5V dc/ 600mA Output, 9 → 18 V dc Input, 3W, Through Hole, +85°C Max Temp -40°C

    View all DC-DC Converters

    Subtotal (1 unit)**

    MYR60.10

    Add to Basket
    Select or type quantity
    Available for back order.*

    * Delivery dates may change based on your chosen quantity and delivery address.

    Units
    Per Unit
    1 +MYR60.10

    **price indicative

    RS Stock No.:
    126-3533
    Mfr. Part No.:
    CC3-1205SF-E
    Manufacturer:
    TDK-Lambda
    Find similar products by selecting one or more attributes.
    Select all

    Brand

    TDK-Lambda

    Output Voltage

    5V dc

    Input Voltage Range

    9 → 18 V dc

    Power Rating

    3W

    Input Voltage Nominal

    12 V dc

    Output Current

    600mA

    Mounting Type

    Through Hole

    Isolated

    Yes

    Number of Outputs

    1

    Output Voltage Adjustment Range

    4.75 → 6V

    Package

    DIP

    Isolation Voltage

    500V ac

    Width

    16.6mm

    Depth

    8.5mm

    Length

    22.86mm

    Series

    CC-E

    Load Regulation

    40mV

    Maximum Temperature

    +85°C

    Efficiency

    79%

    Minimum Temperature

    -40°C

    Standards Met

    CE, cULus, EN 60950-1, NEMKO, UL/CSA 60950-1
