- RS Stock No.:
- 263-9216
- Mfr. Part No.:
- 6009-IEC-Bl
- Manufacturer:
- Electro PJP
1 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each
MYR63.02
Units | Per Unit |
1 + | MYR63.02 |
- RS Stock No.:
- 263-9216
- Mfr. Part No.:
- 6009-IEC-Bl
- Manufacturer:
- Electro PJP
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- FR
Product Details
The Electro PJP alligator clip have w/4 mm female type banana jack socket. It has optimum jaw design to clean well a lot of various items as bar, wire, screw and PCB pin. This alligator clip have IP2X touch proof protection on the jaws when closed and the 4 mm female to prevent accidental contacts and handling is easy by the syringe type ergonomics. The color of the product is blue and it has nickel-coated steel, steel, and brass type conductors. The operating temperature range is -20 °C to +60 °C.
RoHS compliant
Weight is 0.027 kg and overall length of the product is 153 mm
1000 V CAT II / 1000 V CAT III / 600 V CAT IV, reinforced insulation, 20 A (at +40 °C)
Weight is 0.027 kg and overall length of the product is 153 mm
1000 V CAT II / 1000 V CAT III / 600 V CAT IV, reinforced insulation, 20 A (at +40 °C)
Specifications
Attribute | Value |
---|---|
Current Rating | 20A |
Jaw Opening | 12mm |
Contact Material | Nickel-Plated Steel |
Insulated | Yes |
Colour | Blue |
