Hirose DF3 Series Female Crimp Terminal, 28AWG Min, 24AWG Max
- RS Stock No.:
- 175-0616
- Mfr. Part No.:
- DF3-2428SCF
- Manufacturer:
- Hirose
60000 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each (On a Reel of 10000)
MYR0.099
| Units | Per Unit | Per Reel* |
| 10000 - 10000 | MYR0.099 | MYR990.00 |
| 20000 - 90000 | MYR0.096 | MYR960.00 |
| 100000 + | MYR0.093 | MYR930.00 |
| *price indicative | ||
- RS Stock No.:
- 175-0616
- Mfr. Part No.:
- DF3-2428SCF
- Manufacturer:
- Hirose
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
Low profile design with the mounting height of 6.8mm
Achieves the multi-harness by the full automatic ID machine in combination with the DF11 series ID type.
Crimp Socket: Low profile design with mounting height 7.5mm.
Provide the contact crimping area with the sufficient space, and secures the stable crimping operation.
The board can be connected horizontally or vertically in combination with the straight header with the right angle header.
For horizontal connection, the board to board size is the low profile of 6.6mm.
Compatibility with the in-line plug allows the receptacle to set the board side to the receptacle and the cable side to the plug in the board to cable connection.
The board pre-fixed kink is treated with the post pin.
The style employs a scoop-proof and sturborn box type.
This SMT header is equipped with the metal tab to prevent peeling in the solder joint area.
Achieves the multi-harness by the full automatic ID machine in combination with the DF11 series ID type.
Crimp Socket: Low profile design with mounting height 7.5mm.
Provide the contact crimping area with the sufficient space, and secures the stable crimping operation.
The board can be connected horizontally or vertically in combination with the straight header with the right angle header.
For horizontal connection, the board to board size is the low profile of 6.6mm.
Compatibility with the in-line plug allows the receptacle to set the board side to the receptacle and the cable side to the plug in the board to cable connection.
The board pre-fixed kink is treated with the post pin.
The style employs a scoop-proof and sturborn box type.
This SMT header is equipped with the metal tab to prevent peeling in the solder joint area.
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Gender | Female |
| For Use With | Discrete Wire Connectors |
| Series | DF3 |
| Maximum Wire Size mm² | 0.2mm² |
| Termination Method | Crimp |
| Contact Plating | Tin |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 24AWG |
| Contact Material | Phosphor Bronze |
| Maximum Contact Resistance | 30mΩ |
| Minimum Operating Temperature | -35°C |
| Maximum Current | 3A |
| Maximum Operating Temperature | +85°C |
