Sanyo Denki San Ace 9LG Series Axial Fan, 24V dc, 420 m³/h, 38.4 W, 1.6 A Max 120 mm 120mm 38 mm

RS Stock No.:: 862-1630
Distrelec Article No.:: 301-16-830
Mfr. Part No.:: 9LG1224P1G001
Manufacturer:: Sanyo Denki

Sanyo Denki San Ace 9LG Series Axial Fan, 24V dc, 420 m³/h, 38.4 W, 1.6 A Max 120 mm 120mm 38 mm

Subtotal (1 unit)*

MYR542.58

FREE delivery for orders over RM 500.00

Stocked by manufacturer

Ready to ship from 26 January 2027

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per Unit
1 +	MYR542.58

*price indicative

RS Stock No.:: 862-1630
Distrelec Article No.:: 301-16-830
Mfr. Part No.:: 9LG1224P1G001
Manufacturer:: Sanyo Denki

Specifications

Technical data sheets

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Sanyo Denki
	Product Type	Axial Fan
	Supply Voltage	24V dc
	Power Consumption	38.4W
	Maximum Current	1.6A
	Air Flow	420m³/h
	Noise Level	62dB
	Fan Speed	6550rpm
	Direction of Curve	Backward
	Terminal Type	Screw
	Bearing Type	Ball
	Fan Frame Size	120 mm
	Fan Frame Type	Square
	Depth	38mm
	Height	120mm
	Width	120mm
	Standards/Approvals	RoHS
	Series	San Ace 9LG

	Select all
	Brand Sanyo Denki
	Product Type Axial Fan
	Supply Voltage 24V dc
	Power Consumption 38.4W
	Maximum Current 1.6A
	Air Flow 420m³/h
	Noise Level 62dB
	Fan Speed 6550rpm
	Direction of Curve Backward
	Terminal Type Screw
	Bearing Type Ball
	Fan Frame Size 120 mm
	Fan Frame Type Square
	Depth 38mm
	Height 120mm
	Width 120mm
	Standards/Approvals RoHS
	Series San Ace 9LG

Sanyo Denki 9LG1224P1G001 Long life fan datasheet

COO (Country of Origin):: PH

Sanyo Denki DC Axial Fan, 24V DC, 420m³/h Air Flow - San Ace 120L 9LG Series - 9LG1224P1G001

Use this axial fan from Sanyo Denki to cool down your industrial equipment. The high rotation speed of 6550rpm means the propellers move at a fast rate to generate an efficient air flow of 420m³/h. An integrated ball bearing keeps the fan balanced to protect it from vibrations and mechanical wear. Thanks to its minimal noise level of 62dB, this unit operates quietly and won't disrupt regular activities in your work area.

Features & Benefits

• Operating voltage range of 15 to 30V DC for use in low-voltage applications

• Aluminium frame for resistance to impact and corrosion

• Light weight of 420g means it places minimal strain on equipment

• Reverse polarity protection to prevent damage from electrical hazards

• Broad operating temperature range between -20°C and +70°C for use in harsh environments

Applications

• Networking equipment

• Electrical cabinets

• HVAC systems

How long does this axial fan last?

This fan has a long mechanical service life of 180,000 hours, which is approximately 20 years. This makes it a long-lasting choice that won't need frequent maintenance or replacement.

San Ace Long Life High Air Flow DC Fans - L Series

Sanyo Denki San Ace long life, low power DC fans are high air flow and are designed to meet the requirements for applications that must operate without maintenance for extended periods.

Long life

High air flow

High static pressure

Low power consumption

Low noise

PWM speed control function
