ebm-papst RG 125 N Series Axial Fan, 24 V dc, DC Operation, 88m³/h, 4.9W, 240mA Max, 180 x 180 x 40mm
- RS Stock No.:
- 191-7811
- Mfr. Part No.:
- RG125-19/14N/2
- Manufacturer:
- ebm-papst
18 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Price Each
MYR333.17
Units | Per Unit |
|---|---|
| 1 - 4 | MYR333.17 |
| 5 - 9 | MYR326.18 |
| 10 - 24 | MYR316.18 |
| 25 - 49 | MYR308.53 |
| 50 + | MYR301.87 |
- RS Stock No.:
- 191-7811
- Mfr. Part No.:
- RG125-19/14N/2
- Manufacturer:
- ebm-papst
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- HU
Product Details
Applications: Catering, Decentralised building ventilation, Electronics Enclosures, Medical, Recuperators, Safety, Sorting equipment, Traction.
Designed for applications with limited space
Airflow is at right angles to the intake
High static pressure capabilities
Connections are wire ended
Locked rotor protection
Ball bearing type
High temperature low power operation
Airflow is at right angles to the intake
High static pressure capabilities
Connections are wire ended
Locked rotor protection
Ball bearing type
High temperature low power operation
Specifications
Attribute | Value |
|---|---|
| Supply Voltage | 24 V dc |
| Height | 180mm |
| AC or DC Operation | DC |
| Power Consumption | 4.9W |
| Width | 180mm |
| Maximum Current | 240mA |
| Depth | 40mm |
| Dimensions | 180 x 180 x 40mm |
| Air Flow | 88m³/h |
| Termination Type | Lead Wire |
| Noise Level | 57dB |
| Bearing Type | Ball |
