MEAN WELL 12W Plug-In AC/DC Adapter 5V dc Output, 2.4A Output

RS Stock No.:: 706-6476
Mfr. Part No.:: GE18I05-P1J
Manufacturer:: MEAN WELL

MEAN WELL 12W Plug-In AC/DC Adapter 5V dc Output, 2.4A Output

13 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ

Added

Price Each

MYR137.30

Units	Per Unit
1 - 9	MYR137.30
10 - 49	MYR134.41
50 +	MYR130.40

RS Stock No.:: 706-6476
Mfr. Part No.:: GE18I05-P1J
Manufacturer:: MEAN WELL

Technical data sheets

Datasheet

Legislation and Compliance

Product Details

ErP Plug-In Travel Power Supply, Energy Saving, 10W to 24W

Energy saving power supplies
ErP level VI
No load power consumption< 0.3W
Meets EISA 2007 (Energy Independence and Security Act) for 5∼24V
Class II power (without earth pin)
Overload, overvoltage and short circuit protection
LED power on indicator
Compatible with UK (1783436), Euro (1783437), US (1783438), Australian (1783435) and mixed plugs (1783439) (Plugs Not Included)
Output lead fitted with a centre positive 2.1mm jack plug
EMC compliance to FCC part 15, EN55022 class B, GB9254 class B
Harmonic compliance to EN 61000-3-2,3

Note

Conforms to Energy-related Product Directive 2009/125/EC.

Power derates above 30°C.
MTBF to MIL-HDBK-217F.

Standards

UL60950-1, CSA C22.2, TUV EN60950 -1, CCC GB4943

Approvals

TUV, CCC, UL recognised for Canada & US, C-Tick

Switch Mode - Mean Well

Specifications

Attribute	Value
Adapter Type	Plug-In Adapter
Plug Type	Australia/China, European Plug, UK, US/Japan
Output Voltage	5V dc
Input Voltage	100 V ac, 110 V ac, 115 V ac, 120 V ac, 127 V ac, 220 V ac, 230 V ac, 240V ac
Output Current	2.4A
Maximum Temperature	+50°C
Output Connector	2.1 x 5.5 x 11 mm Centre Positive
Input Connector	Universal Plug
Number of Outputs	1
Power Rating	12W
Cable Length	1.5m
Standards Met	ErP Compliant
MTBF	100000h
Load Regulation	±5%
Energy Efficiency Level	VI
Length	81mm
Minimum Temperature	-10°C
Depth	40.5mm
Width	43mm
Type	AC/DC Adapter
