JST, SMR Male Connector Housing, 2.5mm Pitch, 2 Way, 1 Row

  • RS Stock No. 161-3451
  • Mfr. Part No. SMR-02V-N
  • Manufacturer JST
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

The SM series are 2.5mm pitch, wire-to-wire connectors that perform reliably in high-density, small current applications.

High contact pressure
Secure lock mechanism
Mountable on panels of various thickness without using tools.
The contacts are individually surrounded by housing walls.

Specifications
Attribute Value
Number of Contacts 2
Number of Rows 1
Pitch 2.5mm
Gender Male
Mounting Type Through Hole
Series SMR
For Use With SM Connectors
Body Orientation Straight
Length 8mm
Width 7.5mm
Housing Material PBT
1050 Within 4 working day(s) (Global stock)
2300 Within 6 working day(s) (Global stock)
Price Each (In a Pack of 50)
MYR 0.41
units
Per unit
Per Pack*
50 - 50
MYR0.41
MYR20.50
100 - 150
MYR0.386
MYR19.30
200 +
MYR0.28
MYR14.00
*price indicative
