Black Button Tactile Switch, SPST-NO 50 mA 0.7mm

  • RS Stock No. 917-4087
  • Mfr. Part No. SKRPABE010
  • Manufacturer Alps Alpine
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Alps SKRP Series Tactile Switch

Alps Tactile or Tact switches are SPST snap action switches to be used with small currents. This series also provide a minimum rating of 10 μA at 1 V dc and a maximum rating of 50 mA at 12 V dc. These Tact switches have SMT terminals, low contact resistance, high contact reliability and come in a wide selection of operating forces and switching travels.

Suitable for use in a wide variety of applications, such as audio & visual equipment and automotive applications.
Available in various actuator types, such as flat stems & joint stems.
Various actuator colours are also available, to ensure your application is covered.

Tactile

Specifications
Attribute Value
Contact Configuration SPST-NO
Terminal Type Surface Mount
Actuator Length 0.7mm
Actuator Colour Black
Actuator Type Button
Contact Current Rating 50 mA
Operating Force 1.57 N
Height 2.5mm
Voltage Rating 16V dc
1310 In Global stock for delivery within 4 - 6 working days
Price Each (In a Bag of 10)
MYR 1.47
units
Per unit
Per Bag*
10 - 40
MYR1.47
MYR14.70
50 - 90
MYR1.351
MYR13.51
100 - 240
MYR1.254
MYR12.54
250 - 490
MYR1.149
MYR11.49
500 +
MYR1.092
MYR10.92
*price indicative
