White Button Tactile Switch, Single Pole Single Throw (SPST) 50 mA 0.84mm Surface Mount

  • RS Stock No. 917-4080
  • Mfr. Part No. SKRTLAE010
  • Manufacturer Alps Alpine
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Alps SKRT Series Tactile Switch

Alps Tactile or Tact switches are SPST snap action switches to be used with small currents. This series also provide a minimum rating of 10 μA at 1 V dc and a maximum rating of 50 mA at 12 V dc. These Tact switches have SMT terminals, low contact resistance, high contact reliability and come in a wide selection of operating forces and switching travels.

Suitable for use in a wide variety of applications, such as audio & visual equipment and automotive applications.
Available in various actuator types, such as flat stems & joint stems.
Various actuator colours are also available, to ensure your application is covered.

Tactile

Specifications
Attribute Value
Contact Configuration Single Pole Single Throw (SPST)
Switch Operation Momentary
Actuator Length 0.84mm
Actuator Colour White
Actuator Type Button
Length 4.5mm
Width 3.4mm
Dimensions 4.5 x 3.4mm
Mounting Type Surface Mount
Contact Current Rating 50 mA
Operating Force 1.6 N
Operating Temperature Range -40 → +90°C
Height 3.3mm
Minimum Operating Temperature -40°C
Maximum Operating Temperature +90°C
Voltage Rating 12V dc
50 Within 4 working day(s) (Global stock)
770 Within 6 working day(s) (Global stock)
Price Each (In a Bag of 10)
MYR 2.13
units
Per unit
Per Bag*
10 - 40
MYR2.13
MYR21.30
50 - 90
MYR2.045
MYR20.45
100 - 240
MYR1.943
MYR19.43
250 - 490
MYR1.629
MYR16.29
500 +
MYR1.501
MYR15.01
*price indicative
