RS PRO Brass Hex Standoff Male/Female, 15mm, M5 x M5


7750 In stock for delivery within 4 working days
Add to Basket

Price Each (In a Bag of 50)

MYR2.082

units

Added

RS Stock No.:
806-6635
Manufacturer:
RS PRO
unitsPer unitPer Bag*
50 - 100MYR2.082MYR104.10
150 - 300MYR2.029MYR101.45
350 - 700MYR1.944MYR97.20
750 +MYR1.81MYR90.50
*price indicative

RS Pro Nickel Plated Brass Hexagonal Threaded Standoffs


From RS Pro a range of robust, high-quality hexagonal shaped standoffs made from nickel plated brass with a metric internal thread or threaded stud on either end. These versatile standoffs are designed to securely mount your PCB as well as elevating it from other components such as the inside of a computer chassis or another PCB. They are also ideal for improving airflow space around components when the equipment becomes hot. These stand-offs are available in a range of different heights and threads sizes to suit a wide range of PCB applications

What are Threaded Standoffs?
Standoffs are used to separate a PCB by a set distance from other components or a base board serving a similar function as spacers. These standoffs are available with male-female or female-female configurations to suit a wide range of PCB applications. The female-female has an internal thread either end. The male-female has an internal thread one end and an external threaded stud or screw the other to enable components to be joined together.

Features and Benefits
• Versatile and easy to fit
• Hexagonal design allows tightening with a wrench
• Lock PCB securely into place
• Brass material for mechanical strength and resistance to high-temperature environments. Metal standoffs also keep electrical conductivity when looking to maintain a circuit
• Nickel plating for resistance to corrosion

Questions and Answers

How do the Standoffs Fit Together?
The correct size standoff is selected and inserted into or aligned with pre-drilled holes in the PCB. A metric screw or a nut is then fastened onto or into the thread of the standoff to lock and hold it securely in place. The nuts and screws can be released and retightened as required. A male standoff can be screwed into a female standoff providing the threads are the same size.

Where are these Standoffs used?
These standoffs are used in various electronic applications for creating spacing between individual PCBs where they act as spacers and to separate PCB boards from other components. The brass construction of these stand-offs means they are ideal for use in applications where high mechanical strength is required and in high-temperature environments. These applications range from consumer electronics and office machinery to datacoms and telecommunications equipment.


Spacers - Threaded

AttributeValue
Body Length15mm
Thread SizeM5 x M5
Gender TypeMale/Female
MaterialBrass
Body ShapeHex
Stud Length8mm
Thread Size AM5
Thread Size BM5
Hex Size Across Flat8mm
Hole Depth13mm
FinishNickel Plated
