RS PRO Solenoid Valve, 2 port , NO, 24 V dc

  • RS Stock No. 144-0817
  • Manufacturer RS PRO
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): IT
Product Details

RS Pro Industrial Solenoid Valves

The RS Pro series of solenoid valves are a range of 2 way valves which are pilot operated. They can be used for liquid or gas and range in size from 3/8 inch to 2 inch.

Features and Benefits

• Made from forged brass • Pilot operated
• Choice of 230 V ac or 24 V dc operation
• 2 port, normally open (NO) and normally closed (NC)
• Liquid or gas use
• Full range of sizes from 3/8 in to 2 in

Product Application Information

Ideal for fluid control uses in a wide range of industrial and commercial applications such as; Autoclaves
Cooling plant and equipment
Watering plant
Fire extinguishing systems
Hygienic and sanitary
Water jet machinery

Specifications
Attribute Value
Supply Voltage 24 V dc
Number of Ports 2
Operation Pilot
Connection 1-1/4 NC
Default Valve Position NO
Suitable Applications Gas, Liquid
Body Material Brass
Maximum Working Pressure 12 bar
Operating Temperature Range -20 → +90 °C
Minimum Operating Temperature -20°C
Maximum Operating Temperature +90°C
Series SOL
Thread Standard or Connection Type G
Flow Factor Kv 17m³/h
1 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 1,635.43
units
Per unit
1 +
MYR1,635.43
