WIKA S-11 Series Pressure Sensor, 0bar Min, 10bar Max, Current Output
- RS Stock No.:
- 190-9713
- Mfr. Part No.:
- 9021230
- Manufacturer:
- WIKA
6 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each
MYR3,534.60
| Units | Per Unit |
| 1 + | MYR3,534.60 |
- RS Stock No.:
- 190-9713
- Mfr. Part No.:
- 9021230
- Manufacturer:
- WIKA
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
High-quality product
Many configurations possible
Flush process connection
Large stocks for short delivery items
Vacuum-tight
Applications
General industrial applications
Food and beverage industry
Filling and packing machinery
Dosing technology
Level measurement
Many configurations possible
Flush process connection
Large stocks for short delivery items
Vacuum-tight
Applications
General industrial applications
Food and beverage industry
Filling and packing machinery
Dosing technology
Level measurement
Specifications
Attribute | Value |
|---|---|
| Minimum Pressure Reading | 0bar |
| Maximum Pressure Reading | 10bar |
| Accuracy | ±0.5 % |
| Output Type | Current |
| Media Measured | Adhesive, Contaminated Media, Crystallising, Particle-Laden, Paste-Like, Viscous |
| Process Connection | G1/2 |
| Analogue Output | 4 → 20 mA |
| Electrical Connection | Angular connector DIN 175301-803 A |
| Series | S-11 |
| Maximum Current | 20 mA |
| Supply Voltage | 10 → 30 V dc |
| Housing Material | Stainless Steel |
| IP Rating | IP65 |
| Maximum Operating Temperature | +100°C |
| Minimum Operating Temperature | -30°C |
| Mounting Type | Thread Mount |
