- RS Stock No.:
- 177-0544
- Mfr. Part No.:
- 16201
- Manufacturer:
- Volkel
Stock check temporarily unavailable - call for stock availability
Added
Price Each
MYR725.78
| Units | Per Unit |
| 1 + | MYR725.78 |
Calibration Options:
- RS Stock No.:
- 177-0544
- Mfr. Part No.:
- 16201
- Manufacturer:
- Volkel
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
- COO (Country of Origin):
- DE
Product Details
Volkel Go Ring Gauge
The Volkel No-Go ring gauge M18x2.5 is calibrated at a measurement laboratory using IAC thread scanners. It is possible to manually screw into the entire thread of the part without using excessive force. The reference temperature for parts and gauge is 20°C. It is made from high-quality raw material. This gauge is mostly used as an inspection tool.
Features and Benefits
• Metric measurement system
• 6g tolerance
• High durability and reliability
• Compact size and rugged
• Easy to use
• Accurate
• 6g tolerance
• High durability and reliability
• Compact size and rugged
• Easy to use
• Accurate
Certifications
• ISO1502
• DIN13
• DIN13
Certifications
• ISO1502
• DIN13
• DIN13
Specifications
Attribute | Value |
|---|---|
| Plug/Ring | Ring |
| Gauge Type | Ring Thread Gauge |
| Go / No Go | Go |
| Thread Size | M18 x 2.5 |
| Pitch Diameter | 2.5mm |
| Tolerance | 6g |
| Imperial or Metric | Metric |
