SFH 320 FA-Z ams OSRAM, ±60 ° IR Phototransistor, Surface Mount 2-Pin Top LED package
- RS Stock No.:
- 912-8295
- Mfr. Part No.:
- SFH 320 FA-Z
- Manufacturer:
- ams OSRAM
In Global stock for delivery within 4 - 6 working days
Added
Price Each (On a Reel of 2000)
MYR0.887
| Units | Per Unit | Per Reel* |
| 2000 - 8000 | MYR0.887 | MYR1,774.00 |
| 10000 + | MYR0.799 | MYR1,598.00 |
| *price indicative | ||
- RS Stock No.:
- 912-8295
- Mfr. Part No.:
- SFH 320 FA-Z
- Manufacturer:
- ams OSRAM
Technical data sheets
Legislation and Compliance
Product Details
Phototransistor TOPLED® Package
This family of NPN phototransistors, from OSRAM Opto Semiconductors, are from their TOPLED® series. The TOPLED® phototransistors have a surface mount (SMD) PLCC-2 package with a clear or daylight diffused lens.
Features of the TOPLED® phototransistors:
High linearity
PLCC-2 package
Surface mounted (SMD)
Half angle: 60°
Suitable for all soldering methods
High linearity
PLCC-2 package
Surface mounted (SMD)
Half angle: 60°
Suitable for all soldering methods
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
IR Phototransistors, OSRAM Opto Semiconductors
Specifications
Attribute | Value |
|---|---|
| Spectrums Detected | Infrared |
| Typical Fall Time | 8µs |
| Typical Rise Time | 8µs |
| Maximum Dark Current | 50nA |
| Angle of Half Sensitivity | ±60 ° |
| Polarity | NPN |
| Number of Pins | 2 |
| Mounting Type | Surface Mount |
| Package Type | Top LED |
| Dimensions | 3.4 x 3 x 1.92mm |
| Collector Current | 15mA |
| Spectral Range of Sensitivity | 750 → 1120 nm |
| Minimum Wavelength Detected | 750nm |
| Maximum Wavelength Detected | 1120nm |
| Height | 1.92mm |
| Collector Emitter Voltage | 35 V |
| Width | 3mm |
| Length | 3.4mm |
| Saturation Voltage | 150mV |
