BPV11F Vishay, 30 ° IR Phototransistor, Through Hole 2-Pin 5mm (T-1 3/4) package

  • RS Stock No. 159-6488
  • Mfr. Part No. BPV11F
  • Manufacturer Vishay
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): PH
Product Details

BPV11 Series Phototransistors

The BPV11 series, from Vishay Semiconductor, are a family of silicon NPN phototransistors. They come in standard 5mm (T-1 3/4) packages with either a clear or black plastic package. The black packages offer a daylight blocking filter for ambient visible light. The BPV11 series are suitable for use as detectors in industrial electronic circuitry, measurement and control.

Features of the BPV11 phototransistors:
5mm (T-1 3/4) package
Through-hole mounting
3-pins
High radiant sensitivity
Fast response times
Angle of half intensity: 30°
Operating temperature: -40 to +100 °C

IR Phototransistors, Vishay Semiconductor

Specifications
Attribute Value
Spectrums Detected Infrared
Typical Fall Time 5µs
Typical Rise Time 6µs
Number of Channels 1
Maximum Light Current 9000µA
Maximum Dark Current 50nA
Angle of Half Sensitivity 30 °
Polarity NPN
Number of Pins 2
Mounting Type Through Hole
Package Type 5mm (T-1 3/4)
Dimensions 5.75 x 5.75 x 8.6mm
Collector Current 50mA
Width 5.75mm
Height 8.6mm
Spectral Range of Sensitivity 900 → 980 nm
Minimum Wavelength Detected 900nm
Maximum Wavelength Detected 980nm
Length 5.75mm
