Samtec BCS Series Straight Through Hole Mount PCB Socket, 4-Contact, 2-Row, 2.54mm Pitch, Solder Termination
- RS Stock No.:
- 197-6542
- Mfr. Part No.:
- BCS-104-L-D-PE-BE
- Manufacturer:
- Samtec
Temporarily out of stock - back order for despatch 10/05/2024, delivery within 4 working days from despatch date
Added
Price Each
MYR13.41
| Units | Per Unit |
| 1 - 4 | MYR13.41 |
| 5 - 24 | MYR13.13 |
| 25 - 99 | MYR12.73 |
| 100 - 249 | MYR12.43 |
| 250 + | MYR12.15 |
- RS Stock No.:
- 197-6542
- Mfr. Part No.:
- BCS-104-L-D-PE-BE
- Manufacturer:
- Samtec
Technical data sheets
Legislation and Compliance
Product Details
The Samtec BCS series is a 2.54mm tiger claw pass through socket strip having phosphor bronze as contact material. It has 4.6 A per pin current and 475 VAC voltage.
Insulation material made up of Black Liquid Crystal Polymer
Operating Temperature Range -55°C to +125°C
RoHS Compliant
Lead–Free Solderable
Operating Temperature Range -55°C to +125°C
RoHS Compliant
Lead–Free Solderable
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 4 |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Type | PCB Socket |
| Mounting Type | Through Hole |
| Body Orientation | Straight |
| Termination Method | Solder |
| Series | BCS |
