1513504-1 TE Connectivity - WiFi (Dual Band) Multi-Band Antenna, SMT

Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

TE Connectivity SMT Dual-Band Antennas

The professional range of surface mount (SMT) dual-band antenna is intended for use in Bluetooth and 902.11 applications.
The antenna provides excellent performance at a low cost.

PCB ground is to be on top layer
Minimum or no matching circuits required

Surface Mount Technology (SMT) Antennas

Specifications
Attribute Value
RF Protocols WiFi (Dual Band)
Internal/External Internal
Supported Frequency Bands 2400 → 2483.5 MHz
Antenna Physical Form Round
Antenna Mounting Type SMD
Connector Type SMT
Gain 4dBi
Antenna Directivity Omnidirectional
Temporarily out of stock - back order for despatch 06/11/2019, delivery within 4 working days from despatch date
Price Each (In a Pack of 9000)
MYR 3.514
units
Per unit
Per Pack*
9000 +
MYR3.514
MYR31,626.00
*price indicative
