Grey 10 A Flush Mount Rocker Light Switch Grey 20 mm, 2 Way Screwed Matte, 1 Gang BS Standard, 250 V ac 95mm Neon IP66

  • RS Stock No. 705-1676
  • Mfr. Part No. K56401GRY
  • Manufacturer MK Electric
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

10A Switches

250Vac
Knock out cable entry on each side
Supplied with earth and loop terminals

Standards

BS.3676 (Pt.1: 1989); BS EN 60529 (1992)

Supplied with

Earth Terminal and a Loop Terminal in the Back Box

MK Masterseal Water Tight

MK Masterseal range of water tight accessories are specifically designed to provide power and control in environments heavily exposed to dust and water splashing. Grey units are ideally suited to harsh industrial, commercial and agricultural applications whilst the new white version is designed for the food industry.

IP56-IP65 (dependant on product) rated against dust, water and impact up to 500g
Wide operating temperature range -5°C to + 40°C

Specifications
Attribute Value
Switch Type Rocker
Number of Gangs 1
Number of Poles 1
Number of Ways 2
Mount Type Flush
Current Rating 10 A
IP Rating IP66
Colour Grey
Material Polycarbonate
Series Masterseal
Voltage Rating 250 V ac
Finish Matte
Illumination Neon
Faceplate Fixing Screwed
Minimum Box Depth 38mm
Width 95 mm
Depth 57 mm
Faceplate Depth 20 mm
Colour Shade Grey
Length 95 mm
Fixing Standard BS Standard
Termination Type Captive Screw
Height 95mm
225 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 123.48
units
Per unit
1 +
MYR123.48
