Startech VGA over CATx KVM Extender, 300m

  • RS Stock No. 123-8064
  • Mfr. Part No. SV565UTPUL
  • Manufacturer Startech
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): TW
Product Details

SV565UTPUL HDMI KVM Extender

The SV565UTPUL Long Range USB VGA KVM Console Extender over Cat5 UTP (1000 ft) lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 1000ft (300m) away.You can use your existing USB keyboard, USB mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.This product is backed by a Startech.com 3-year warranty with free lifetime technical support.

Features & Benefits

High resolution support: Up to 1920x1200(WUXGA)/ 1600x1200(UXGA) Kit includes both local and remote units Compatibility mode enables hotkey commands to be passed to connected StarView KVMs Max Resolution Limit feature caps the resolution to prevent the resolution setting from exceeding the capability of the connected display USB computers are supported at the host and remote locations (USB keyboard and mouse required for remote console) Supports auto-switching between host and remote users or dedicated control Compatible with CAT 5, 5e, or 6 UTP cabling Intuitive hotkey commands Hotkey controlled Equalizer(sharpness), Gain(brightness), and RGB Skew adjustments Supports most combo keyboard and mouse sets (including Wireless) PS/2 and USB host PC's supported via the appropriate PS2 or USB KVM cable (USB style included)Great for high definition resolutions, with support of UXGA (1600 x 1200) and WUXGA (1920 x 1200) Remote to local switching means that the computer or console being extended can still be accessed locally without the need to unplug/replug any connections

Applications

Control remote machines and security monitoring systems Monitor computer-controlled equipment in a factory or warehouse at a distance Use one or more servers in a server room from a remote location Allow two users to share one PC or KVM

What's in the box?

KVM Extenders (1x Local, 1x Remote) 2n1 USB VGA KVM Cables Rubber Feet Universal power adapter: comes ready for NA/EU/UK only when you buy in NA/EU/UK; comes ready for Australia and New Zealand only when you buy in Australia and New Zealand User Manual

KVM Extenders

Specifications
Attribute Value
Type Extender Pair
Video Connection Type VGA
Number of Ports 2
Keyboard/Mouse Connection Type USB
Number of Displays Supported 1
Transmission Method CATx
Maximum Resolution 1920 x 1200
Extension Distance 300m
Receiver Dimensions 157 x 70 x 20mm
Transmitter Dimensions 157 x 70 x 20mm
Receiver Depth 70mm
Receiver Height 20mm
Receiver Width 157mm
Transmitter Depth 70mm
Transmitter Width 157mm
Transmitter Height 20mm
7 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 2,535.04
units
Per unit
1 +
MYR2,535.04
