RS PRO Carbon Steel Female Hydraulic Quick Connect Coupling 3/8 in

  • RS Stock No. 733-5628
  • Manufacturer RS PRO
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
COO (Country of Origin): IT
Product Details

Carbon Steel Male Tip / Female Flat Face Coupler

Connection via hand or tool under maximum working pressure
Withstands high static pressures
Maximum flow rate maintained should light unscrewing of the sleeve occur
Large operating temperature range -25 → +100 °C
Nitrile seal material
Carbon steel body construction

Standards

ISO-DIS 16028

Screw Locking

Couplings manufactured to ISO standards and fitted with NBR (Nitrile) or VITON® seals, with secondary PTFE seals for backup purposes. Suitable for working environments within -25 to 100°C (+125°C for PVVM and VVS series), and -10 to +200°C for VITON-seal screw couplings.

Warning

  • Do not connect couplings under pressure.
Specifications
Attribute Value
Series RS
Compatible With ISO-DIS 16028
Type Union
Coupling Gender Female
Locking Style Screw Lock
Thread Rp 3/8 Female
Material Carbon Steel
Finish Yellow Passivated, Zinc Plated
Seal Material Nitrile Rubber
Thread Size 3/8in
Thread Standard Rp
Thread Gender Female
Maximum Operating Pressure 350 bar
Maximum Operating Temperature +100°C
Minimum Operating Temperature -25°C
42 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 89.56
units
Per unit
1 - 5
MYR89.56
6 - 11
MYR85.79
12 +
MYR84.44
