Heavy Duty Foot Switch, Die Cast Aluminium Momentary Double Pole Double Throw (DPDT) 21 A 250V IP67

  • RS Stock No. 228-2103
  • Manufacturer RS PRO
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

Heavy Duty Guarded

Rugged heavy duty guarded foot switches.

Features and Benefits:

Non-latching and alternate action versions which are guarded to prevent accidental operation
Stock no. 208-3265 has two stage operation whereby one set of N/C + N/O contacts operate before the other N/C + N/O contacts during full actuator travel
Screw terminals and self-lifting clamp for connection of leads 2x1.5mm2 or wire up to 2x2.5mm2
Sealed to IP67

Typical Applications

Foot switches are commonly used in applications where hands-free control is more practical or safer. They can be found on:
Industrial machinery and smaller power tools
Hospital beds
Dentist Chairs
Lamps

FAQs

What are the different types of switching options?
Switches are components that switch a circuit on or off by making contact or breaking contact, the two most common are:

Non-latching (Momentary) – this type of foot switch makes contact when you push it but breaks contact when you release it.

Latching (Maintained) – this type of foot switch needs to be pressed once for ON and again for OFF.

Why would you use a footswitch?
As these switches are operated by the person’s feet, this means that their hands are free so therefore allows the individual to multitask.

Approvals

EN60204-1/EN 60947-5-1

Specifications
Attribute Value
Contact Configuration Double Pole Double Throw (DPDT)
Switch Operation Momentary
Case Material Die Cast Aluminium
Contact Voltage Rating AC 250V
Contact Current Rating 21 A
Switch Environment Heavy Duty
IP Rating IP67
Contact Material Silver
Width 163mm
Colour Yellow
Height 155mm
Dimensions 264 x 163 x 155mm
Standards Met BEAB Approved, CE, CSA, DEMCO, EN 60730, EN 61058, IMQ, KEMA, NEMCO, OVE, SEMCO, SETI, SEV, UL, VDE
Length 264mm
Guard Cover Yes
29 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 1,131.49
units
Per unit
1 - 5
MYR1,131.49
6 - 11
MYR1,094.26
12 +
MYR1,078.90
