Telegartner TOC Series Male RJ45 Connector, Panel Mount, Cat6a

RS Stock No.:: 878-2444
Mfr. Part No.:: J60026A0000
Manufacturer:: Telegartner

Telegartner TOC Series Male RJ45 Connector, Panel Mount, Cat6a

Temporarily out of stock - back order for despatch 06/05/2024, delivery within 4 working days from despatch date

Added

Price Each

MYR739.96

Units	Per Unit
1 - 1	MYR739.96
2 - 4	MYR719.24
5 - 9	MYR689.63
10 +	MYR670.40

RS Stock No.:: 878-2444
Mfr. Part No.:: J60026A0000
Manufacturer:: Telegartner

Technical data sheets

TOC IP68 Cat6 MFP8 RJ45 plug set

Legislation and Compliance

COO (Country of Origin):: DE

Product Details

Telegärtner DataVoice TOC IP68 Outdoor Cat 6 RJ45 MFP8 T568B Plug Set

TOC IP68 outdoor Cat 6 RJ45 MFP8 T568B plug set suitable for use in harsh environment machine and plant engineering applications with a temperature range of -40 to +85°C. Installation requires just one turning movement to lock and seal the connection. This cat 6 RJ45 RJ45 MFP8 T568B plug set is suitable for10 Gigabit ethernet transmission acc. to IEEE 802.3an and PoE+ acc. to IEEE 802.3at and has a nickel plated brass housing, a clear PC UL94 V0 contact housing, 360° shielding and accepts a cable insulation diameter of 1.0 to 1.6mm and cable outer diameter of 4 to 9.5mm. An IP68 bulkhead plug protective cap is available separately, please see stock number 878-2498

Standards

Connector standard to IEC 60603-7-51 (500 MHz)
Category 6A: ANSI/TIA/EIA-568-C.2
Category 6: ISO/IEC 11801, DIN EN 50173-1
IP68 protection to IEC 60529

Telegärtner DataVoice TOC IP68 Outdoor RJ45 Couplers, Plug Sets and Bulkhead Sets

Specifications

Attribute	Value
Ethernet Connector Type	RJ45 Connector
Gender	Male
LAN Category	Cat6a
Mounting Type	Panel Mount
Number of Ways	8P8C
Shield Type	Shielded
Orientation	Straight
IP Rating	IP68
Length	68.7mm
Width	36 (Dia.)mm
Series Number	J60026A0000
Series	TOC
Contact Material	Brass (Shield Contact), Spring Steel
Contact Plating	Nickel
