KNITTER-SWITCH 16 Way Through Hole DIP Switch, Rotary Shaft Actuator
- RS Stock No.:
- 702-3362
- Mfr. Part No.:
- DRS4016
- Manufacturer:
- KNITTER-SWITCH
5 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
8 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each
MYR16.79
| Units | Per Unit |
| 1 - 9 | MYR16.79 |
| 10 - 49 | MYR16.45 |
| 50 - 99 | MYR15.97 |
| 100 - 249 | MYR15.58 |
| 250 + | MYR15.25 |
- RS Stock No.:
- 702-3362
- Mfr. Part No.:
- DRS4016
- Manufacturer:
- KNITTER-SWITCH
Technical data sheets
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Subminiature Rotary Coded Switches - DRR and DRS 3000 & 4000 Series
Through hole mount
Contact resistance: < 100 mΩ
Insulation resistance: > 1000 MΩ at 250 V DC
Mechanical life: minimum 20 000 operations
Contact resistance: < 100 mΩ
Insulation resistance: > 1000 MΩ at 250 V DC
Mechanical life: minimum 20 000 operations
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
PCB Mounting
Footprint/pin spacing: 2.54mm between pins and 5.08mm between rows
Specifications
Attribute | Value |
|---|---|
| Number of Positions | 16 |
| Mounting Type | Through Hole |
| Contact Material | Gold Plated |
| Package Style | DIP |
| Actuator Type | Rotary Shaft |
| Contact Current Rating | 30 mA@ 15 V dc |
| Mechanical Life | 20000Operations |
| Maximum Operating Temperature | +75°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +75°C |
| Voltage Rating | 15V dc |
| Dielectric Strength | 250V ac |
