16 Way Through Hole DIP Switch 16P, Rotary Shaft Actuator

  • RS Stock No. 319-3818
  • Mfr. Part No. A6A-16RS
  • Manufacturer Omron
Technical data sheets
Legislation and Compliance
RoHS Status: Not Applicable
Product Details

DIP Sealed Rotary Switches (IP64)

A range of PCB mount sealed rotary DIP switches. Series includes a standard type that can be operated from the top or side, spindle shaft type that can be operated while mounted on a panel, along with thumbwheel and flat options.

Fully sealed to IP64
RoHS compliant
10 or 16way switching positions
Switching capacity 1mA to 0.1A @ 5 to 28Vdc
Contact resistance 200mΩ max.
Ambient temperature -10 to +70°C
Footprint/Pin spacing: 2.54mm between pins and 5.08 between rows
Gold plated contacts

PCB Mounting

Footprint/pin spacing: 2.54mm between pins and 5.08mm between rows

Specifications
Attribute Value
Contact Configuration 16P
Contact Current Rating 100 mA@ 30 V dc
Contact Material Silver over Gold Plated Phosphor Bronze
Number of Positions 16
Mounting Type Through Hole
Actuator Type Rotary Shaft
Package Style DIP
Mechanical Life 10000Operations
Maximum Operating Temperature +70°C
Minimum Operating Temperature -10°C
Operating Temperature Range -10 → +70°C
Dielectric Strength 500V ac
