RS PRO 3P+E DIN 43650 A Solenoid Connector, Female, Screw, 10A, 24 V dc

  • RS Stock No. 896-2123
  • Manufacturer RS PRO
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): IN
Product Details

Din Connector Sockets, 3 Pole plus Earth, Illuminated, Type A

A selection of 3 pole and earth illuminated DIN connector sockets in a variety of voltage ratings. These screw mount sockets are Type A with a PG9 gland size and and are of transparent polycarbonate construction, with a Nitrile/silicon gasket.

Features and Benefits:
• 2 Pole + earth
• Type A socket Type
• Gland size PG-9
• Contact resistance 20mΩ max.
• Permissible Temperature 0 to 90°C

//media.rs-online.com/t_line/L8962123-01.jpg
Specifications
Attribute Value
Pole Format 3P+E
DIN 43650 Type DIN 43650 A
Voltage Rating 24 V dc
Gender Female
Indicator Light Yes
Mounting Type Screw
Cable Gland Size PG9
Colour Clear
Current Rating 10A
45 In Global stock for delivery within 4 - 6 working days
Price Each (In a Pack of 5)
MYR 8.708
units
Per unit
Per Pack*
5 - 70
MYR8.708
MYR43.54
75 - 245
MYR8.406
MYR42.03
250 +
MYR8.04
MYR40.20
*price indicative
