- RS Stock No.:
- 260-7580
- Mfr. Part No.:
- EF50086B.3M
- Manufacturer:
- Times Microwave
6 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
21 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price 1 Reel of 3 Metre(s)
MYR689.25
| Reel(s) | Per Reel | Per Metre* |
| 1 + | MYR689.25 | MYR229.75 |
| *price indicative | ||
- RS Stock No.:
- 260-7580
- Mfr. Part No.:
- EF50086B.3M
- Manufacturer:
- Times Microwave
Technical data sheets
Legislation and Compliance
Product Details
Coaxial Cable RG402, 405
Cable for microwave applications made of silver-coated, copped plated steel strand, with a
PTFE dielectric. The shielding can be made of copper or aluminium (AL-TP). With aluminium, the cable is easier to shape and lighter in weight (over 40% lighter).
PTFE dielectric. The shielding can be made of copper or aluminium (AL-TP). With aluminium, the cable is easier to shape and lighter in weight (over 40% lighter).
Specifications
Attribute | Value |
|---|---|
| Terminated/Unterminated | Unterminated |
| Coaxial Type | RG405/U |
| Outer Diameter | 2.2mm |
| Characteristic Impedance | 50 Ω |
| Length | 3m |
| Conductor Strand Type | Solid |
| Minimum Operating Temperature | -40°C |
| Size of Strands | 0.51 mm |
| Sheath Material | Aluminium |
| Maximum Operating Temperature | +125°C |
| Operating Temperature Range | -40 → +125 °C |
| Number of Strands | 1 |
| Insulation Material | PTFE |
| Conductor Material | Silver Plated Copper |
| Core Strands | 1/0.51 |
| Capacitance | 105pF/m |
