MEAN WELL GC120A12 Battery Charger For Lead Acid, Lithium-Ion 13.6V 7.5A with R7B plug
- RS Stock No.:
- 747-1702
- Mfr. Part No.:
- GC120A12-R7B
- Manufacturer:
- MEAN WELL
5 In Global stock for delivery in 4-6 working days, delivery time may vary for certain locations or FTZ
Added
Price Each
MYR406.51
| Units | Per Unit |
| 1 + | MYR406.51 |
- RS Stock No.:
- 747-1702
- Mfr. Part No.:
- GC120A12-R7B
- Manufacturer:
- MEAN WELL
Technical data sheets
Legislation and Compliance
Product Details
120W Single Output Battery Charger
2 stage charging characteristic
Universal AC input / Full range
No load power consumption<0.5W
3 pole AC inlet IEC320-C14
Class I power ( with earth pin)
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Fully enclosed plastic case
2 color LED indicator for charging status
Approvals: TUV / UL / CB / FCC / CE
2 years warranty
Built-in active PFC function, PF>0.
Universal AC input / Full range
No load power consumption<0.5W
3 pole AC inlet IEC320-C14
Class I power ( with earth pin)
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Fully enclosed plastic case
2 color LED indicator for charging status
Approvals: TUV / UL / CB / FCC / CE
2 years warranty
Built-in active PFC function, PF>0.
Specifications
Attribute | Value |
|---|---|
| Chemistries Charged | Lead Acid, Lithium-Ion |
| Output Voltage | 13.6V |
| Charge Current | 7.5A |
| Plug Type | R7B |
| Number of Batteries Charged | 1 |
| Input Voltage | 85 → 264V ac |
| Number of Charge Stages | 2 |
| Model Number | GC120A12 |
| Dimensions | 167 x 67 x 35mm |
| Weight | 620g |
