Mascot Battery Charger For Lead Acid 12V 1A
- RS Stock No.:
- 478-4077
- Mfr. Part No.:
- 2240000060
- Manufacturer:
- Mascot
In Global stock for delivery within 4 - 6 working days
Added
Price Each
Was MYR288.30
You pay
MYR251.83
| Units | Per Unit |
| 1 + | MYR251.83 |
- RS Stock No.:
- 478-4077
- Mfr. Part No.:
- 2240000060
- Manufacturer:
- Mascot
Technical data sheets
Legislation and Compliance
Product Details
Mascot Battery Charger
The Mascot 2240 series lead-acid battery charger has a 3-colour LED charge status indicator and crocodile clip output. This 3-stage battery charger is waterproof and shockproof. It requires an input voltage between 90VAC and 264VAC. This charger is ideal for medical applications. The 3-stage regime permits the charger to be left connected indefinitely. The output voltage rating is 6V and the current rating is 1.3A.
Note:
Chargers are not supplied with mains leads, these should be ordered separately for 2040 series see stock no. RS 452-669 and 873-0702 and UK, RS 321-203 DK, NO, SE, DE and AT, BE and NL for 2240 and 9940 series see stock no. RS 452-669. For Australia / NZ mains lead see RS 488-2806
Note:
Chargers are not supplied with mains leads, these should be ordered separately for 2040 series see stock no. RS 452-669 and 873-0702 and UK, RS 321-203 DK, NO, SE, DE and AT, BE and NL for 2240 and 9940 series see stock no. RS 452-669. For Australia / NZ mains lead see RS 488-2806
Features and Benefits
Protection against reverse voltage and short circuit
Temperature ranges between -10℃ and 40℃
Mounting brackets are available separately
AC plug to IEC 320/2-pin C8
Temperature ranges between -10℃ and 40℃
Mounting brackets are available separately
AC plug to IEC 320/2-pin C8
Certifications
IP67 rated
EN 60950
EN 60601-1 3ed
EN 60335-2-29
EN 60950
EN 60601-1 3ed
EN 60335-2-29
Specifications
Attribute | Value |
|---|---|
| Chemistries Charged | Lead Acid |
| Output Voltage | 12V |
| Charge Current | 1A |
| Number of Batteries Charged | 1 |
| Input Voltage | 90 → 264V ac |
| Batteries Included | No |
| Maximum Output Power | 12W |
| Number of Charge Stages | 3 |
| Dimensions | 90 x 45 x 32mm |
| Weight | 120g |
