Mascot 1 Cell 4.2V 1.3A 5.5W Battery Pack Charger for Lithium-Ion batteries, AUS, EURO, UK, USA Plug

  • RS Stock No. 211-326
  • Mfr. Part No. 2241 LI 1 ELEMENT
  • Manufacturer Mascot
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): NO
Product Details

Li-Ion battery pack chargers, 2240 LI series

Cut-out power supply charger for Li-Ion batteries.
3 charge control stages.
Automatic detection of completed charge.
Protected against current overloads and polarity reversal.
Includes EU, UK, US & AUS input plugs plus 2.1mm & 2.5mm output plugs
Approved for medical devices: EN 60601

Supplied with

EU, UK, US & AUS input plugs plus 2.1mm & 2.5mm output plugs

Mascot Li-Ion Battery Charger

The Mascot 1.3A battery pack charger is used for charging 1 cell of lithium-ion batteries. This 3-stage battery charge requires an input voltage that ranges between 90VAC and 264VAC. This lithium-ion battery charger is ideal for medical applications. The 3-stage regime permits the charger to be left connected indefinitely. The charger comes with EU, UK, US & AUS input plugs plus 2.1mm & 2.5mm output plugs. Its output voltage rating is 4.2V.
Supplied with:
EU, UK, US and AUS input plugs plus 2.1mm and 2.5mm output plugs
Li-Ion battery pack chargers

Features and Benefits

• 3-step charge control with current detection as charge termination
• Universal input voltage (90VAC to 264VAC)
• Charging 1-7 battery cells
• Maximum output power is 5.5W
• Order mains cord separately
• Waterproof (IP67) version available
• Exchangeable AC and DC plugs
• Custom specifications on request

Certifications

• IP67 rated

Li-Ion battery pack chargers

Specifications
Attribute Value
Battery Sizes Charged Battery Pack
Chemistries Charged Lithium-Ion
Number of Cells Charged 1
Plug Type AUS, EURO, UK, USA
Dimensions 90 x 45 x 32mm
Input Voltage 90 → 264V ac
Maximum Output Power 5.5W
Weight 115g
17 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 315.98
units
Per unit
1 +
MYR315.98
