ebm-papst 3400N Series Axial Fan, 92 x 92 x 25.4mm, 102m³/h, 2.9W, 12 V dc

  • RS Stock No. 878-1057
  • Mfr. Part No. 3412NHH-RS0
  • Manufacturer ebm-papst
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

ebm-papst 3400N Series Plug n' Play DC Axial Fans

Ebm-papst make the mounting and installing of their fans even easier with the Plug n’ Play versions of their 3400N series fans. With pre-fitted molex connector and threaded brass inserts, Plug n’ Play compact axial fans save you time and effort while installing.

Features and Benefits

• Air exhaust over struts
• Connection via fitted molex connector
• IP20 protection


With their easy installation and high service life, these Plug N’ Play fans are ideal for PC cooling applications.


Q: Is the fan easy to operate?

A:With completely integrated electronic communication, the fans require little input from the user to operate. The threaded brass inserts are ideal for quick and easy mounting, while the pre-fitted molex connector means that no complex wiring is required for connection.

Q: Is the fan durable?

A: 3400N series Plug N’ Play axial fans have plastic housing, and are protected against a degree of particle ingress as standard.

Q: Are there accessories available for this fan?

A: There is a finger guard (512-575) and filter (200-7643) available for this series of fans.

Attribute Value
Supply Voltage 12 V dc
Dimensions 92 x 92 x 25.4mm
Height 92mm
AC or DC Operation DC
Width 92mm
Power Consumption 2.9W
Depth 25.4mm
Air Flow 102m³/h
Noise Level 39dB
Fan Speed 3250rpm
Bearing Type Ball
Fan Housing Shape Square
Special Features Air Exhaust Over Bars
Termination Type Lead Wire
Series 3400N
16 In Global stock for delivery within 4 - 6 working days
Price Each
MYR 181.75
Per unit
1 - 4
5 - 11
12 - 24
25 - 49
50 +
