Sanyo Denki, 12 V dc, DC Axial Fan, 80 x 80 x 38mm, 156m³/h, 11.28W

  • RS Stock No. 781-5073
  • Mfr. Part No. 9GA0812P1S61
  • Manufacturer Sanyo Denki
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): PH
Product Details

San Ace Low Power DC Fans - GA Series

San Ace GA series low power DC fans are a highly power efficient solution to a range of fan requirements. Featuring high air flow, high static pressure and low noise.

Low power high performance fans offering 15% to 38% energy saving over conventional fans
Improved impeller, guided vanes, reduced mass, reduced noise by between 2dB and 6dB
PWM control to further optimise power consumption and noise level (except 60 x 60 x10 mm frame size which have tachometer output only)
High static pressure and high airflow
Static pressure optimised at inflection point where fan operated for high impedance applications
30,000 to 60,000 hour life fans @ 60 Degree C
Permanently lubricated dual ball bearing system

Specifications
Attribute Value
Supply Voltage 12 V dc
Dimensions 80 x 80 x 38mm
Height 80mm
AC or DC Operation DC
Width 80mm
Power Consumption 11.28W
Maximum Current 940mA
Depth 38mm
Air Flow 156m³/h
Noise Level 59dB
Fan Speed 9550rpm
Bearing Type Ball
18 In Global stock for delivery within 4 - 6 working days
Price Each
Was MYR187.37
MYR 151.06
units
Per unit
1 - 4
MYR151.06
5 - 11
MYR149.07
12 - 24
MYR147.13
25 - 49
MYR145.26
50 +
MYR143.42
