Delphi Metri-Pack 630 Series, 2 Way Cable Mount Plug Connector, with Crimp Termination Method

  • RS Stock No. 896-1871
  • Mfr. Part No. 12034269
  • Manufacturer Delphi
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Delphi Metri-Pack 630 Sealed Male Automotive Connectors

From Delphi, a range of robust male housings from the Metri-Pack 630 series. These automotive connectors are designed to exceed requirements for marine, appliance and industrial control applications. Made from a tough PBT housing material, these connectors have an excellent resistance to temperature, chemicals and abrasion. The automotive connector housings can accommodate a cable range of 0.50 – 5.0 mm2 cable and utilise contacts with a 6.3mm blade width.
Contacts and cable seals must be purchased separately.See typical part numbers 896-1916 for terminals and 896-1925 cable seals.

Delphi Metri-Pack 630 Series Automotive Connectors

Specifications
Attribute Value
Number of Contacts 2
Type Connector
Gender Male
Current Rating 46A
Mounting Type Cable Mount
Series Metri-Pack 630
Colour Black
Termination Method Crimp
Height 21.7mm
Width 28.5mm
Depth 56.1mm
Maximum Operating Temperature +125°C
Minimum Operating Temperature -40°C
Housing Material PA 73
Contact Plating Tin
Contact Material Tin Brass
420 In Global stock for delivery within 4 - 6 working days
Price Each (In a Pack of 10)
MYR 5.963
units
Per unit
Per Pack*
10 - 90
MYR5.963
MYR59.63
100 - 240
MYR5.666
MYR56.66
250 - 490
MYR5.506
MYR55.06
500 - 990
MYR5.346
MYR53.46
1000 +
MYR5.177
MYR51.77
*price indicative
