Delphi Metri-Pack 630 Series, 3 Row 4 Way Cable Mount Socket Connector, with Crimp Termination Method

  • RS Stock No. 896-1764
  • Mfr. Part No. 12065686
  • Manufacturer Delphi
Technical data sheets
Legislation and Compliance
RoHS Certificate of Compliance
Product Details

Delphi Metri-Pack 630 Sealed Female Automotive Connectors

From Delphi, a range of robust female housings from the Metri-Pack 630 series. These automotive connectors are designed to exceed requirements for marine, appliance and industrial control applications. Made from a tough PBT housing material, these connectors have an excellent resistance to temperature, chemicals and abrasion. The automotive connector housings can accommodate a cable range of 0.50 – 5.0 mm2 cable and utilise contacts with a 6.3mm blade width.
Contacts and cable seals must be purchased separately. Typical part number 896-1802 for terminals and 896-1925 cable seals.

Delphi Metri-Pack 630 Series Automotive Connectors

Specifications
Attribute Value
Number of Contacts 4
Type Connector
Gender Female
Number of Rows 3
Current Rating 46A
Mounting Type Cable Mount
Series Metri-Pack 630
Colour Black
Termination Method Crimp
Height 41.3mm
Width 34.7mm
Depth 31.5mm
Minimum Operating Temperature -40°C
Maximum Operating Temperature +125°C
Contact Plating Tin
Housing Material PA 6
Contact Material Tin Brass
100 In Global stock for delivery within 4 - 6 working days
Price Each (In a Pack of 2)
MYR 34.88
units
Per unit
Per Pack*
2 - 18
MYR34.88
MYR69.76
20 - 48
MYR33.145
MYR66.29
50 - 98
MYR32.205
MYR64.41
100 - 198
MYR31.265
MYR62.53
200 +
MYR30.29
MYR60.58
*price indicative
